- May 2024 SMC eConnect Newsletter May 17, 2024
- Product May 17, 2024
3-Screen Display Condensation Checker PSH
(Digital Temperature & Humidity Switch)
- Visualization of relative humidity
Real-time digital display - Remote/Condition monitoring
Remote confirmation via switch output preventing condensation problems! - Detects abnormalities prior to condensation generation
Click here for product info.
Air Management System AMS20/30/40/60
- Air consumption: Max. 62% reduction
Monitors the machine standby conditions (when production stops) and automatically decreases the pressure
Reduce unnecessary air consumption - Compatible with OPC UA
Direct connection enables data communications - Compatible with wireless system
Communication distance: Max. 100m - Compatible with OPC UA, PROFINET, EtherNet IP & EtherCAT
Click here for product info.
Continue reading → - Visualization of relative humidity
- Technical Tips May 17, 2024
3-Screen Display Condensation Checker PSH
(Digital Temperature & Humidity Switch)
Air Management System AMS20/30/40/60 Series
Reduced air consumption by lower pressure during equipment standby (Standby mode)
FAQ
Click here for more FAQs of products.
New Product Launching
JSX Series - The pilot operated JSXD series (N.O. specification) has been added. [New]
- A direct operated vacuum type (JSX□□V series) has been added. [New]
- A direct operated steam type (JSX□□S series) has been added. [New]
- A direct operated high pressure type (JSX□□H series) has been added. [New]
- Improved environmental resistance due to the stainless steel coil cover [IP67 enclosure/NEMA4X*]
- *IP65 for models with a DIN terminal
- Space saving
Compact: Valve volume reduced by 25%*, Lightweight: Weight reduced by 30%*
*Compared with the existing model - Energy saving
Coil force: 10% increase*, Power consumption: 14% reduction*
*Compared with the existing model - 360° lead wire insertion and removal is possible.
- Improved weather resistance in outdoor environments
SMC Manifold Controller, JXD1-M* Series - Up to 16 axes can be connected
Max. 8 driver units can be connected - Fanless design (no cooling fan)
No cooling fan = No need to worry about fan replacement - Operating temperature range: 0 to 55°C
- Communication protocol
CC-Link
EtherNet/IP™ - Cables, etc. can be attached from the front
- News May 17, 2024
SMC Vietnam
Opening Ceremony of SMC Automation Lab
In April 2024, SMC Corporation (Vietnam) participated in the Opening Ceremony of SMC Automation Lab in four universities, including East Asia University of Technology, Lac Hong University, Dong Nai University of Technology and Dong Nai College of High Technology. With a total sponsorship value of nearly VND 25,000.000.000, the labs are equipped with SMC’s modern pneumatic automation equipment.
Moreover, SMC Corporation (Vietnam) arranged lecturer training programs in automation, pneumatics, and electro-pneumatics. Students will gain information and skills from this, giving them the chance to access and familiarize themselves with the technologies used in factory production lines. We at SMC Corporation (Vietnam) would like to thank the universities for their invaluable collaboration. We think that this collaboration will serve as the cornerstone of SMC and universities’ enduring partnership.
Soon, the universities will be able to gradually achieve the Sustainable Development Goals (SDGs), particularly education, by using this solid basis to train the next generation of engineers, meet industrial demands for labour, and create a high-quality educational system.
Robocon Kick-Off at Lac Hong University
SMC Corporation (Vietnam) accompanies Lac Hong University to conquer the final round of Robocon Vietnam Contest 2024!
SMC Corporation (Vietnam) had the privilege of attending the Robocon kick-off ceremony at Lac Hong University on April 23, 2024. We are happy to have sponsored the competition, giving the five participating teams equipment valued at over VND 243,000.000, allowing them to build creative and functional robots.
During the event, Mr. Gerald Ho gave the teams kind words of support and encouragement and reaffirmed SMC’s commitment to continuing to journey with LHU on the conquest of creativity and knowledge.
Continue reading →
- May 2024 SMC eConnect Newsletter May 17, 2024
- Produk May 17, 2024
3-Screen Display Condensation Checker PSH
(Saklar Temperatur & Kelembapan Digital)
- Visualisasi kelembaban relatif
Tampilan digital yang aktual - Pemantauan Jarak Jauh/Kondisi
Konfirmasi jarak jauh melalui keluaran sakelar yang dapat mencegah masalah kondensasi - Mendeteksi kelainan sebelum terjadinya kondensasi
Klik di sini untuk produk info.
Air Management System AMS20/30/40/60
- Konsumsi udara: Maks. pengurangan 62%
Memantau kondisi mesin standby (saat produksi berhenti) dan secara otomatis menurunkan tekanan
Mengurangi konsumsi udara yang tidak perlu - Kompatibel dengan OPC UA
Koneksi langsung memungkinkan komunikasi data - Kompatibel dengan sistem nirkabel
Jarak komunikasi: Maks. 100m - Kompatibel dengan OPC UA, PROFINET, EtherNet IP & EtherCAT
Klik di sini untuk produk info.
Continue reading → - Visualisasi kelembaban relatif
- Tips Teknikal May 17, 2024
3-Screen Display Condensation Checker PSH
(Saklar Temperatur & Kelembapan Digital)
Air Management System AMS20/30/40/60 Series
Mengurangi konsumsi udara dengan tekanan yang lebih rendah selama peralatan siaga (Mode Siaga)
FAQ
Klik di sini untuk info lebih lanjut mengenai produk..
Peluncuran Produk Baru
JSX Series - Seri JSXD yang dioperasikan percontohan (spesifikasi N.O.) telah ditambahkan. [Baru]
- Tipe vakum yang dioperasikan langsung (seri JSX□□V) telah ditambahkan. [Baru]
- Jenis uap yang dioperasikan langsung (seri JSX□□S) telah ditambahkan. [Baru]
- Tipe tekanan tinggi yang dioperasikan langsung (seri JSX□□H) telah ditambahkan. [Baru]
- Peningkatan ketahanan terhadap lingkungan karena penutup koil baja tahan karat [penutup IP67/NEMA4X*]
- *IP65 untuk model dengan DIN terminal
- Hemat ruang
Ringkas: Volume katup berkurang 25%*, Ringan: Berat berkurang 30%*
*Dibandingkan dengan model yang sudah ada - Hemat energi
Kekuatan kumparan: peningkatan 10%*, Konsumsi daya: pengurangan 14%*
*Dibandingkan dengan model yang ada - Penyisipan dan pelepasan kabel timah 360° dapat dilakukan.
- Peningkatan ketahanan cuaca di lingkungan luar ruangan
SMC Manifold Controller, JXD1-M* Series - Hingga 16 sumbu dapat dihubungkan
Maks. 8 unit driver dapat dihubungkan - Desain tanpa kipas (tanpa kipas pendingin)
Tidak ada kipas pendingin = Tidak perlu khawatir tentang penggantian kipas - Kisaran suhu pengoperasian: 0 hingga 55°C
- Protokol komunikasi
CC-Link
EtherNet/IP™ - Kabel, dll. dapat dipasang dari depan
- Berita May 17, 2024
SMC Vietnam
Upacara Pembukaan SMC Automation Lab
Pada bulan April 2024, SMC Corporation (Vietnam) berpartisipasi dalam Upacara Pembukaan Lab Otomasi SMC di empat universitas, termasuk East Asia University of Technology, Lac Hong University, Dong Nai University of Technology dan Dong Nai College of High Technology. Dengan total nilai sponsorship hampir VND 25,000.000.000, laboratorium tersebut dilengkapi dengan peralatan otomasi pneumatik modern milik SMC.
Selain itu, SMC Corporation (Vietnam) menyelenggarakan program pelatihan dosen di bidang otomasi, pneumatik, dan elektro-pneumatik. Siswa akan memperoleh informasi dan keterampilan dari sini, memberi mereka kesempatan untuk mengakses dan membiasakan diri dengan teknologi yang digunakan dalam jalur produksi pabrik. Kami di SMC Corporation (Vietnam) mengucapkan terima kasih kepada universitas-universitas atas kerja sama mereka yang sangat berharga. Kami berpendapat bahwa kolaborasi ini akan menjadi landasan kemitraan jangka panjang antara SMC dan universitas.p.
Dalam waktu dekat, universitas-universitas akan mampu secara bertahap mencapai Sustainable Development Goals (SDGs), khususnya pendidikan, dengan menggunakan dasar yang kuat untuk melatih generasi insinyur berikutnya, memenuhi kebutuhan tenaga kerja industri, dan menciptakan sistem pendidikan berkualitas tinggi.
Robocon Kick-Off di Lac Hong University
SMC Corporation (Vietnam) mendampingi Universitas Lac Hong menaklukkan babak final Kontes Robocon Vietnam 2024!
SMC Corporation (Vietnam) mendapat kehormatan untuk menghadiri upacara kick-off Robocon di Universitas Lac Hong pada tanggal 23 April 2024. Kami senang telah mensponsori kompetisi ini, memberikan perlengkapan kepada lima tim peserta senilai lebih dari VND 243,000.000, sehingga memungkinkan mereka untuk membangun robot yang kreatif dan fungsional.
Selama acara, Mr. Gerald Ho memberikan kata-kata dukungan dan dorongan yang baik kepada tim dan menegaskan kembali komitmen SMC untuk terus melakukan perjalanan bersama LHU dalam penaklukan kreativitas dan pengetahuan.
- Tháng 5 năm 2024 SMC eConnect Newsletter May 17, 2024
- Sản phẩm May 17, 2024
Thiết bị kiểm tra độ ngưng tụ hiển thị 3 màn hình PSH
(Cảm biến nhiệt độ và độ ẩm kỹ thuật số)
- Hiển thị độ ẩm tương đối
Màn hình kỹ thuật số thời gian thực - Giám sát/ Điều khiển từ xa
Xác nhận từ xa thông qua các tín hiệu đầu ra của cảm biến giúp ngăn ngừa các vấn đề về ngưng tụ - Phát hiện những bất thường trước khi tạo ra sự ngưng tụ.
Bấm vào ĐÂY để xem thêm thông tin sản phẩm.
Hệ thống quản lý khí AMS20/30/40/60
- Hệ thống quản lý khí
Hệ thống theo dõi tình trạng chờ của máy (khi sản xuất dừng) và tự động giảm áp suất.
Giảm thiểu tiêu thụ khí nén không cần thiết - Tương thích với OPC UA
Kết nối trực tiếp cho phép truyền dữ liệu - Tương thích với hệ thống không dây
Phạm vi kết nối tối đa 100m - Tương thích với OPC UA, PROFINET, EtherNet/IP & EtherCAT
Bấm vào ĐÂY để xem thêm thông tin sản phẩm.
Continue reading → - Hiển thị độ ẩm tương đối
- Mẹo kỹ thuật May 17, 2024
Thiết bị kiểm tra độ ngưng tụ hiển thị 3 màn hình PSH
(Cảm biến nhiệt độ và độ ẩm kỹ thuật số)
Hệ thống quản lý khí AMS20/30/40/60 Series
Giảm mức tiêu thụ khí bằng cách giảm áp suất trong khi thiết bị ở chế độ chờ
Câu hỏi thường gặp
Bấm vào ĐÂY để biết thêm Câu hỏi thường gặp về sản phẩm.
Ra mắt sản phẩm mới
Dòng JSX - Dòng JSXD vận hành gián tiếp qua pilot (Đặc tính kỹ thuật N.O.) [Mới]
- Loại chân không vận hành trực tiếp (dòng JSX□□V) [Mới]
- Loại hơi nước vận hành trực tiếp (dòng JSX□□S) [Mới]
- Loại áp suất cao vận hành trực tiếp (dòng JSX□□H) [Mới]
- Cải thiện khả năng chống chịu với môi trường nhờ vỏ cuộn dây bằng thép không gỉ [Vỏ IP67/NEMA4X*]
- *IP65 cho các model có thiết bị đầu cuối DIN
- Tiết kiệm không gian
Nhỏ gọn: Thể tích van giảm 25%*, Nhẹ: Trọng lượng giảm 30%* *So với mô hình hiện tại
Tiết kiệm năng lượng - Energy saving
Lực cuộn dây: tăng 10%*, Điện năng tiêu thụ: Giảm 14%*
*So với mô hình hiện tại - Có thể lắp và tháo dây dẫn 360°.
- Cải thiện khả năng chống chịu thời tiết ngoài trời
Bộ điều khiển dạng đế, dòng JXD1-M* - Có thể kết nối tối đa 16 trục
Có thể kết nối tối đa 8 bộ điều khiển - Thiết kế không quạt (không có quạt làm mát)
Không có quạt làm mát = Không cần lo lắng về việc thay thế quạt - Phạm vi nhiệt độ hoạt động: 0 đến 55°C
- Giao thức truyền thông
CC-Link
EtherNet/IP™ - Cáp, v.v. có thể cắm từ phía trước
- Tin tức May 17, 2024
SMC Việt Nam
Lễ khánh thành phòng thực hành SMC Automation Lab
Trong tháng 4 vừa qua, SMC Corporation tại Việt Nam đã tham gia sự kiện khánh thành phòng thực hành khí nén – tự động hóa SMC Automation Lab tài trợ cho 04 trường đại học, bao gồm: Đại học Công nghệ Đông Á tại Hà Nội, Đại học Lạc Hồng, Đại học Công nghệ Đồng Nai và Cao đẳng Công nghệ cao Đồng Nai. Với tổng giá trị tài trợ lên tới gần 25 tỷ đồng với trang thiết bị, các trạm thực hành khí nén – tự động hóa hiện đại nhất của SMC.
Song song với việc tài trợ thiết bị, SMC Corporation (Việt Nam) còn tổ chức các khóa đào tạo về khí nén, điện khí nén, và tự động hóa cho đội ngũ giảng viên. Từ đó, chuyển giao kiến thức và kỹ năng đến sinh viên, tạo cơ hội để tiếp cận, làm quen với công nghệ đang được ứng dụng trong các dây chuyền sản xuất tại nhà máy.
SMC Corporation tại Việt Nam xin gửi lời cảm ơn chân thành nhất đến sự hợp tác quý báu từ phía nhà trường. Chúng tôi tin rằng, sự hợp tác này sẽ là nền tảng cho mối quan hệ lâu dài giữa công ty và quý nhà trường. SMC Corporation xem đây là một bước đệm vững chắc để các trường có thể đào tạo ra các thế hệ kỹ sư, đáp ứng đủ nguồn nhân lực cho ngành công nghiệp và kiến tạo nền giáo dục chất lượng, từng bước thực hiện thành công các Mục tiêu Phát triển Bền vững (SDGs) trong thời gian sắp tới, đặc biệt là giáo dục.
Lễ xuất quân đoàn Robocon tham gia cuộc thi sáng tạo robot Việt Nam 2024
SMC Corporation (Việt Nam) đồng hành cùng trường Đại học Lạc Hồng chinh phục vòng Chung kết toàn quốc cuộc thi sáng tạo Robocon Việt Nam 2024!
Ngày 23/4/2024 vừa qua, SMC Corporation (Việt Nam) vinh dự tham dự lễ xuất quân đầy khí thế của 5 đội Robot tranh tài trường Đại học Lạc Hồng, cho vòng chung kết toàn quốc Cuộc thi sáng tạo Robocon Việt Nam năm 2024.
Tự hào là một trong những nhà tài trợ, trao tặng các thiết bị phục vụ cho cuộc thi với tổng giá trị hơn 243 triệu đồng để hỗ trợ cho 5 đội thi, góp phần tạo nên những cỗ máy Robocon đầy sáng tạo và tiềm năng.
Tại buổi lễ, đại diện SMC Corporation (Việt Nam) đã gửi lời động viên, cổ vũ nồng nhiệt đến các bạn sinh viên, đồng thời khẳng định cam kết tiếp tục đồng hành cùng các bạn trên con đường chinh phục tri thức và sáng tạo.
